FNIRSI DSO TC3 Digital Oscilloscope Transistor Tester Function Signal Generator
SPECIFICATIONS
Analog Bandwidth: 500Khz
Automatic measurement: Yes
Battery: 0.1~4.5V
Battery Included: No
Bracket specifications: All-in-one foldable stand
Brand Name: FNIRSI
Capacitor: 5pF~100mF
Certification: CE
Charging specifications: Type-C 5V
Coupling method: AC/DC
DC: 0-3.3V
DHT11: 0-60℃/5-95%
DIY Supplies: Electrical
DS18B20: 0-85℃
Diodes: Forward voltage drop <4.5V
Display screen: 2.4 inch TFT color screen
FNIRSI Model: DSO-TC3
High-concerned chemical: None
Horizontal time base range: 1us-10s
Inductor: 10uH~1000mH
Infrared remote decoding: NEC protocol infrared code
Input resistance: 1MΩ
Input voltage: 0~40V
MOSFET: JFET IGBT MOSFET
Model Number: DSO-TC3
Origin: Mainland China
Pulse wave: 1-100KHz/3.3V/0-100%
Ramp: 1-10KHz/0-3.3V/0-100%
Real-time sample rate: 10MSa/s
Reglulated diode: 0.01~4.5V
Resistor: 0.01Ω~50MΩ
SCR: Turn-on voltage <5V, gate Pole trigger current <6mA
Square wave: 1-100KHz/3.3V/50%
Supply voltage: Rechargeable lithium battery
Test voltage range: 400V
Triangle wave: 1-10KHz/0-3.3V/50%,1-10KHz/0-3.3V/50%
Trigger mode: Auto / Normal / Single
Trigger type: Rising edge / Falling edge
Vertical Sensitivity (x1): 10mV-10V
Waveform Freeze: Yes
